TiAL Q Blow Off Valve BOV

Starting at: $235.00


Please Choose:

Select BOV Flange Type








Aluminum Weld On


Steel Weld On


Tial To Greddy Bolt On Adapter


Tial To HKS Bolt On Adapter




Add to Cart:
  • Model: Tial Q
  • Manufactured by: TiAL

Tial Q BOV (Blow Off Valve) Pick your color & mounting flange. Use the stainless steel flange for steel & stainless pipe & pick aluminum for aluminum pipes. Complete kits comes with everything.

- Tial Q BOV (your pick of color)
- Aluminum mounting clamp with bolt
- Banjo air fitting with bolt, washers & Viton O-ring
- Your pick of:
Aluminum Tube Weld Flange
Steel Tube Weld Flange
Tial TO Greddy bolt on Adapter (allows Tial BOV to bolt on to GReddy BOV flange)
Tial TO HKS bolt on Adapter (allows Tial BOV to bolt on to HKS BOV flange)

For use on turbo-charged and super-charged applications (Paxton, Vortec, etc.). The body and all internal components are CNC-machined from 6061 aluminum alloy. It features a large 1.98 in (50.5mm) valve.

The V-Band design aluminum mounting clamp gives a very clean and unique appearance. The clamp is anodized and uses Stainless Steel hardware for a long lasting, corrosion-free appearance.

The valve seal utilizes a Viton O-ring that is clamped in place to prevent the possibility of sticking to the seat and pulling out. The valve stem and guide are Teflon-lubricated, hard anodize-coated for wear resistance.

The Blow Off Valve also comes with Tial's own machined aluminum banjo-type air fitting and bolt, with over sized 10mm hose barb for quick actuator response. The actuator has a high temp silicone Nomex-reinforced diaphragm for long life.

Through countless hours of R&D we were able to make the same size valve flow a staggering 60% more than the original design - that means 60% more air is blown off per cycle! This is the highest flowing BOV on the market.
